Tinytech Plants


Edible Oil Extraction Machinery


Edible Oil Extraction Machinery
Price : ₹ 4 Lac / PLANT
Get Best Price

Product Details

Capacity 130 Kgs / Hour
Usage ALL KIND OF OIL
Type Oil Press
Brand Name TINYTECH PLANTS
Material Mild Steel
Voltage 420V
Condition New
Power 9-12kw
Driven Type Electric
Phase Three Phase
Warranty 1 Year
Country of Origin India
Corrosion Resistance Yes
Operating Type Semi Automatic
Power Consumption 15 HP
Model Name/Number TINYTECH EDIBLE OIL MACHINERY
Size 22 x 4
Brand TINYTECH PLANTS
Motor 10 HP - 12.5 HP
Man power 2
Foundation Frame Provided
machine life More than 50 years
Filter press Included
Filter table Provided
Spare parts Included
Profit Rs.5000 by working 12 hours
Cake Thickness Adjustable

Additional Information

Min. Order Quantity 1 Piece
Payment Terms T/T
Delivery Time 10-12 Days

Special Facilities / Features In Tinytech Expeller

  • Chamber cage opens on hinges simply by tilting of chamber halves. Drudgery of lifting of heavy weights of clamping bars and chamber halves are totally eliminated.
  • Thickness of oil cake can be changed while running of expeller. This is unique facility. It enables to change thickness of cake while running of expeller. This is unique facility of Tinytech expeller.
  • Oil pump is now integral part of oil expeller and hence no separate pump required.
  • Due to ready foundation frame, No foundation of any machine required in the ground. So Installation becomes easy & plant can be started within 24 hours. Also you can shift machine easily from one place to another as and when required.
  • 6 taper roller bearings make expeller very sturdy and durable. No ball bearings fitted anywhere.
  • As expeller is very compact, it is economical to import by air freight for land locked countries.
  • Feedbox mouth has been made bigger so that expeller can crush cotton seeds effectively.
  • Main pulley Shaft diameter is 62 mm which is highest in the industry.
